型号 | 主要尺寸(in) | 额定负载(N) | 重量(Kg) | |||
XLB | d | D | Bi | Be | Cr | (参考) |
| GW208PPB6 | 1.188 | 3.1496 | 1.437 | 0.708 | 26200 | 0.72 |
| GW209PPB11 | 1.7811 | 3.3464 | 1.437 | 0.866 | 29200 | 0.64 |
| GW209PPB2 | 1.7717 | 3.3464 | 1.189 | 1.189 | 29200 | 0.65 |
| GW209PPB4 | 1.535 | 3.3464 | 1.189 | 1.189 | 29200 | 0.75 |
| GW210PPB2 | 1.938 | 3.5433 | 1.189 | 1.189 | 31500 | 0.71 |
| GW210PPB5 | 1.785 | 3.5433 | 1.189 | 1.189 | 31500 | 0.79 |
| GW211PPB10 | 1.938 | 3.937 | 1.311 | 1.311 | 39100 | 1.02 |
| GW211PPB2 | 2.188 | 3.937 | 1.311 | 1.311 | 39100 | 0.97 |
| GW211PPB9 | 2.194 | 3.937 | 1.311 | 0.984 | 39100 | 0.92 |
| W208PPB2 | 1.5005 | 3.1496 | 1.689 | 0.708 | 26200 | 0.72 |
| W208PPB23 | 1.5005 | 3.1496 | 1.689 | 1.189 | 26200 | 0.68 |
| W208PPB4 | 1.188 | 3.1496 | 1.189 | 1.189 | 26200 | 0.72 |
| W208PPB6 | 1.188 | 3.1496 | 1.437 | 0.708 | 26200 | 0.72 |
| W209PPB11 | 1.7811 | 3.3464 | 1.437 | 0.866 | 29200 | 0.64 |
| W209PPB2 | 1.7717 | 3.3464 | 1.189 | 1.189 | 29200 | 0.65 |
| W209PPB4 | 1.535 | 3.3464 | 1.189 | 1.189 | 29200 | 0.75 |
| W210PPB2 | 1.938 | 3.5433 | 1.189 | 1.189 | 31500 | 0.71 |
| W210PPB5 | 1.785 | 3.5433 | 1.189 | 1.189 | 31500 | 0.79 |
| W211PPB2 | 2.188 | 3.937 | 1.311 | 1.311 | 39100 | 0.97 |
| W208PPB7 | 1 | 3.1496 | 1.189 | 0.708 | 26200 | 0.64 |
